Workbench Accessories
Parallel Guide (set of 2)
$149.00
Table-mounted parallel guides for accurate rips and narrow cuts without attaching to the guide rail. Tool-free adjustment makes repeatable sizing faster and easier.
Quantity
-
+
Add to Cart
Buy Now
Free shipping on orders over $100
Designed in Boulder, CO
Precision. Accuracy. Confidence.
Quality Guaranteed
Rigorously tested and inspected.
30-Day Returns
Satisfaction guaranteed
Direct Support
Talk to Rob, the inventor
<1"
Narrowest Rip Width
¼"
Thinnest Material Supported
2
Sides of the Blade
0
Calibration Required
01 / DESIGN
Anchors into your bench. Not your guide rail.
Most parallel guide systems clamp to your track saw's guide rail, which means the calibration is only as accurate as the rail clamps and the guide rail's position. Dash-Board's Parallel Guides anchor directly into your bench top's 20mm holes or into Track Stars instead. The reference point is the bench, not the rail, and the bench doesn't move.
- Anchors into 20mm bench holes or Track Stars
- No clamping to your guide rail
- Traditional parallel guide calibration not required
- Works on either side of the guide rail
02 / DUAL-HEIGHT
Two ends. Two heights. One guide.
Each Parallel Guide has two different ends with different reference heights. Use the thin end under your guide rail for cutting dimensions narrower than the rail. Use the tall end for stacked material and for when Parallel Guides are on the right side of the blade.
- 6mm end slips under your guide rail for narrow cuts
- 29mm aluminum cap end raises reference height
- Cuts under 1" wide with no additional attachments
- Supports material as thin as ¼"
03 / RIP GAUGE PAIRING
Set stops on both sides of the blade.
Paired with the Rip Gauge, Dash-Board Parallel Guides simplify the process of getting parallel cuts. You use one standard to set both guides, rather than two scales to set two guides. Uniquely, Dash-Board Parallel Guides work on both sides of the blade. You can use the thin side underneath your guide rail for narrow cuts in material as thin as 1/4"/6.5mm. Use the tall end for wider pieces on either side of the guide rail.
- 29mm cap enables Rip Gauge dimension setting
- Same kerf-corrected dimension on both sides of the blade
- Replaces individual guide calibration with a single reference
- Verified upgrade path from TSO and similar traditional designs
04 / SYSTEM
The piece that makes rips repeatable.
The Parallel Guide is the stop. The Rip Gauge sets the standard. The Track Stars are the platform that lets you rip past the bench edge. Together, this is the workflow Dash-Board owners use to retire their table saws. Mount the guides in your bench top for narrower rips. Mount them in Track Stars for the widest rips. Same guides, same workflow, no calibration.
- Mounts in bench top for narrow to medium rips
- Mounts in Track Stars for wider rips
- Built from carbon fiber and aluminum for stiffness and weight
- The system piece that unlocks the rip workflow
Product Specs
What’s in the box:
- 2 Parallel Guides
- 2 aluminum caps
- 4 ExpanDogs
Materials:
- Carbon fiber
- Aluminum
Specifications:
- Length = 15.625” (388mm)
- Width = 1.5” (38mm)
- Height = 6mm to 29mm
Works with these workbenches:
All workbenches with 20mm holes · Dash-Board bench · ShortCut bench · Festool MFT3 & 1080 · Benchdogs Ultra MFT · TrackTubes
Product Safety:
- Be mindful of pinch points
- Secure all hardware before use to avoid accidents or injury.
- Use appropriate lifting form to avoid injury
- Keep out of reach of children
- Workbenches and Outriggers not intended as standing platforms
- For safest operation please keep static loads below 300 lbs or 136 kg
- Disassembly or product alterations are not recommended
- Do not use products for uses other than intended
